The Castair P2B625-13/8 is a 2-groove (2B) replacement motor pulley with a fixed 1-3/8" bore shaft and 6.25" outer diameter, built for Cast Air belt-drive air compressor systems. If your existing motor pulley is worn, cracked, or out of spec, this is the direct replacement — same groove profile, same bore, same OD — so you can get your compressor back in service without fabricating or modifying anything.
Note: Cast Air did not provide a dedicated manufacturer product page for this pulley. Specifications below are drawn from the product listing and standard 2B-groove pulley engineering conventions. Contact us if you need confirmation for a specific compressor application.
What Is a 2B Motor Pulley?
The 2B designation tells you this pulley has two B-section V-belt grooves. B-section belts are the standard for single-phase and three-phase compressor motors in the 1-5 HP range. Two grooves let you run a matched belt pair, which doubles the power transmission capacity versus a single-groove setup and reduces belt slip under load — important for compressors that cycle frequently in a busy shop.
Pulley Specification Details
- Groove Profile: 2B (two B-section V-belt grooves)
- Bore Type: Fixed bore — 1-3/8" (1.375") shaft diameter
- Outer Diameter (OD): 6.25"
- Application: Motor-side pulley for belt-drive air compressors
- Compatibility: Castair belt-drive compressor systems using 1-3/8" motor shafts and B-section belts
- Part Number: P2B625-13/8
Why Motor Pulley OD Matters for Compressor Performance
The motor pulley OD and the pump flywheel OD together define the belt drive ratio — and that ratio determines how fast the compressor pump turns. A 6.25" motor pulley paired with a larger flywheel on the pump creates the speed reduction needed to run most single-stage Cast Air pumps at their correct RPM (typically 900-1,100 RPM on the pump side). Using the wrong pulley OD shifts this ratio, which can over-speed the pump and shorten its life, or under-speed it and cost you CFM. Always verify the OD matches the original before ordering.
Fixed Bore vs. Taper-Lock (SK/SD) Pulleys
- Fixed bore pulleys like the P2B625-13/8 are machined to a specific shaft diameter — in this case 1-3/8". They mount directly to the motor shaft with a keyway and set screw. The correct choice for a direct replacement on an existing motor with the same shaft diameter.
- Taper-lock (SK/SD) pulleys use a separate bushing that allows one pulley to fit multiple shaft diameters. Preferred when future motor swaps are anticipated or shaft diameter may vary.
- If your original pulley was a fixed bore 1-3/8", the P2B625-13/8 is the drop-in replacement. Do not substitute a taper-lock pulley — they require matching bushings and the hub geometry differs.
When Does a Shop Need This Pulley?
- Motor pulley cracked, damaged, or showing V-belt groove wear causing belt slippage or squealing
- Replacing a motor where the new motor has a 1-3/8" shaft — this pulley restores the original drive ratio
- Rebuilding a Cast Air belt-drive compressor and sourcing OEM-spec replacement parts
- Compressor pump RPM is off (verified with a tachometer) and pulley OD needs correction
2B Fixed-Bore 1-3/8" Motor Pulley Size Comparison
Cast Air offers this pulley in multiple OD sizes. Here is how the 2B fixed-bore 1-3/8" bore lineup compares:
- P2B625-13/8 — 6.25" OD — $68.34 (this unit) — smallest in the series; lowest pump RPM for a given motor speed
- P2B675-13/8 — 6.75" OD — $71.23 — slightly larger diameter, increases pump speed for the same motor RPM
- P2B80-13/8 — 8.0" OD — $88.55 — larger pulley, higher pump RPM, used on higher-CFM applications
- P2B875-13/8 — 8.75" OD — $103.95 — largest in the fixed-bore 1-3/8" lineup
Measure the original pulley OD before ordering. If you are not sure, call us — we can help verify the correct replacement for your Cast Air compressor model.
Technical Specifications
- Part Number: P2B625-13/8
- Manufacturer: Cast Air (Castair)
- Groove Type: 2B (two B-section V-belt grooves)
- Bore: Fixed, 1-3/8" (1.375")
- Outer Diameter: 6.25"
- Bore Style: Fixed (keyway and set screw mount)
- Belt Section Compatibility: B-section V-belts (two grooves, matched pair)
- Price: $68.34
- Manufacturer Data: Product page not available — specifications from product listing data
What Is Included
- 1x Castair P2B625-13/8 motor pulley
- Set screw(s) for shaft retention
Belts are not included. Order the appropriate B-section matched belt pair separately for your drive length.
