Castair 240 Gallon Heavy-Duty Horizontal Air Receiver Tank — 200 PSI, Part 240HD200
The Castair 240HD200 is the heavy-duty version of the 240-gallon horizontal air receiver tank, rated for 200 PSI maximum working pressure. At $3,926.69 — approximately $511 more than the standard 240H200 — the heavy-duty designation reflects a more substantial construction specification suited for more demanding installation environments or continuous industrial duty cycles.
If you are sizing a receiver tank for a high-production environment, a compressor running extended duty cycles, or an installation where the tank will see frequent pressure cycling, the heavy-duty construction of the 240HD200 is the appropriate choice. For standard shop air storage needs, the 240H200 handles the job at lower cost. Call us if you are not certain which applies to your situation — that is what we are here for.
Tank Specifications
- Part Number: 240HD200
- Capacity: 240 gallons
- Orientation: Horizontal
- Maximum Working Pressure (MAWP): 200 PSI
- Construction: Heavy-duty (heavier shell, upgraded specifications)
- Manufacturer: Cast Air (Castair)
- Price: $3,926.69
Heavy-Duty vs. Standard — What the Difference Means in Practice
The standard 240H200 and the heavy-duty 240HD200 are both 240-gallon horizontal tanks rated for 200 PSI. The HD designation typically indicates:
- Heavier shell plate thickness: A thicker tank wall means more material between the compressed air and the outside environment — better suited for industrial environments, corrosive atmospheres, or systems where the tank is expected to run at or near maximum pressure consistently
- Higher connection ratings: Larger or heavier-rated inlet/outlet fittings in some configurations
- Extended service life expectation: The additional material in the shell gives the tank more corrosion allowance over its service life
For a definitive comparison of what specifically differs between the 240H200 and 240HD200 on your order, contact us — we can pull the specification sheets for both tanks.
What a 240-Gallon Receiver Tank Does for Your System
- Pressure stabilization: Large demand events draw from the tank rather than directly from the compressor, smoothing out pressure drops at the tool or process
- Compressor cycle reduction: A large receiver extends the time between compressor start cycles, reducing motor starts per hour and extending motor and pump life
- Peak demand buffering: High-flow tools, spray equipment, and pneumatic automation draw large volumes in short bursts — 240 gallons of storage absorbs these peaks
- Moisture separation: The receiver provides residence time for compressed air, allowing moisture to fall out and collect at the drain
Horizontal Configuration — Installation Considerations
- Lower ceiling clearance required: Horizontal tanks fit under standard ceiling heights where vertical tanks of the same capacity would not
- Saddle mounting: Horizontal tanks mount on saddle supports — verify the mounting arrangement and anchor requirements for your installation
- Drain at lowest point: Plan condensate drain line routing from the low point on the tank shell
- Floor footprint: A 240-gallon horizontal tank requires significant floor length — get full dimensions before committing to a location
When Does a Shop Need the HD Version vs. the Standard?
- Continuous duty industrial environments: Facilities running compressors at high duty cycles where the tank cycles pressure frequently benefit from heavier construction
- Corrosive or high-humidity environments: Extra wall thickness provides more corrosion allowance in environments that are hard on metal equipment
- High-pressure systems running near 200 PSI regularly: If your system operates close to the 200 PSI MAWP as a matter of routine, the heavier construction of the HD version provides more margin
- Standard shop air buffer storage: The standard 240H200 is sufficient — the HD is not required for typical shop use
Technical Specifications
- Part Number: 240HD200
- Manufacturer: Cast Air (Castair)
- Capacity: 240 gallons
- Orientation: Horizontal
- MAWP: 200 PSI
- Construction: Heavy-duty
- List Price: $3,926.69
Note: Detailed dimensional and construction specifications were not available at time of writing. Contact us for full dimensional data and a comparison with the standard 240H200 before ordering.
