The Castair G151860U is a 1/8-inch NPT bottom-mount pressure gauge with a 1.5-inch dial face, reading 0 to 60 PSI. Priced at $11.01, this is the bottom-mount, low-range version of Cast Air's 1.5-inch gauge — the port exits from the base of the gauge housing for vertical installation off horizontal fittings.
Like the G151860B, this gauge is calibrated for low-pressure monitoring rather than tank or supply line pressure. The 0-60 PSI scale provides the resolution you need when monitoring regulated downstream pressure — whether that is a regulator set for air tools, a spray gun station, or a pneumatic control circuit. At 60 PSI full scale, a 5 PSI adjustment at the regulator is clearly visible on the dial rather than nearly imperceptible on a wide-range gauge.
Key Features
- 1/8 inch NPT connection — fits standard regulator gauge ports, manifold fittings, and small system taps
- Bottom-mount configuration — port exits from the base for upright installation off horizontal fittings
- 1.5-inch dial — compact gauge for confined spaces
- 0-60 PSI range — appropriate for regulated downstream pressure monitoring
- Genuine Cast Air component — matched replacement for Cast Air regulator and system installations
Technical Specifications
- Part Number: G151860U
- Connection: 1/8 inch NPT
- Mount: Bottom mount
- Dial Size: 1.5 inch
- Range: 0-60 PSI
Which Gauge Do You Need?
Cast Air's 1.5-inch gauge lineup covers four combinations of mount type and range: back-mount 0-160 PSI (G151816B), bottom-mount 0-160 PSI (G151816U), back-mount 0-60 PSI (G151860B), and bottom-mount 0-60 PSI (this gauge, G151860U). Choose the 0-60 PSI range for regulated low-pressure monitoring. Choose bottom-mount when your gauge port is horizontal and the gauge needs to stand upright. If in doubt, call us and describe your installation.
Applications
- Downstream regulator pressure monitoring for air tool stations
- Spray gun and paint booth regulator outlet gauges
- Low-pressure pneumatic system pressure indication
- Replacement gauge on Cast Air regulator assemblies
