Castair CLB112112 — 1-1/2" x 1-1/2" Inline Check Valve, NPT Female Inlet/Outlet
The CLB112112 is a 1-1/2-inch by 1-1/2-inch NPT female inline check valve from Castair. It is the largest unit in the Castair CLB inline check valve series, built for high-volume industrial compressed air distribution systems where main line pipe size reaches 1-1/2 inches.
This check valve allows compressed air to flow in one direction only. When upstream pressure drops below downstream pressure — on compressor shutdown, during standby, or in multi-compressor installations — the valve closes to prevent backflow. Female NPT connections on both ends thread directly into standard pipe fittings, manifolds, or flanged adapters.
What This Unit Does
- One-Way Flow Control: Prevents reverse flow in the compressed air line when upstream pressure drops. The check closes automatically — no manual operation required.
- 1-1/2" NPT Female Both Ends: Threads onto male nipples or male-threaded fittings on each end. Standard pipe threads — no special adapters or custom fittings needed.
- Inline Body: Straight-through installation in the distribution line — no offset connections, no need to cut and reroute pipe around the valve.
- Industrial Scale: At 1-1/2-inch, this unit serves systems with very high air volume flow — large industrial plants, multi-compressor manifolds, high-demand production environments.
Castair Inline Check Valve Lineup (CLB Series)
- CLB1414 (1/4" x 1/4"): NPT Female — control lines and light-duty drops
- CLB1212 (1/2" x 1/2"): NPT Female — small shop and garage
- CLB3434 (3/4" x 3/4"): NPT Female — mid-size commercial
- CLB1010 (1" x 1"): NPT Female — main line industrial/commercial
- CLB112112 (1-1/2" x 1-1/2"): NPT Female — high-volume industrial distribution
Technical Specifications
- Part Number: CLB112112
- Inlet Size: 1-1/2" NPT Female
- Outlet Size: 1-1/2" NPT Female
- Body Style: Inline — straight-through flow path
- Connection Type: NPT Female both ends
- Series: CLB Inline Check Valve
- Manufacturer: Castair, Spicer, Minnesota
